Most modules are project specific - please contact us today to get started on a module for your project.
Truly Opto's compact camera modules have both COB and CSP manufacturing processes. Truly can produce up to 21 mega pixel modules and has its own high precise wafer cutting production line.
Variety of CCM Products: High pixel, super aperture, optical anti-shake, fast focusing, high dual CAM (with optical zoom, bokeh or super night function), face recognition, iris recognition, fisheye, 360°Panoramic, 3D gesture, and surrounding view for automobile.
Leading Technology: Truly has the world's leading CSP and automatic COB chip packaging technology, high precise wafer cutting technology, high resolution stain control technology, and self-developed high-precision dual CAM AA correction algorithm.
Widespread Applications: Truly's camera module has been widely used in Smart phone, intelligent driving, smart home appliances, professional office equipment, uav/robot, tablet PC, automotive, and industrial and medical.
| Camera | Resolution | pixel | sensor | Serializer | lens | Fov(H/V) | Size (mm) (L/W/H) | |||
| ADAS 8M | 3840x2160 | 8M | OX08B40 | MAX96717 | 8G+IRF | 70° | 39.3° | 23 | 23 | 43.75 |
| ADAS 8M ADAS 8M | 3840 21603840x2160 | 8M8M | OX08B40 OX08B40 | MAX96717 MAX96717 | 8G IRF 8G+IRF | 120120° | 5454° | 2525 | 2525 | 4646 |
| ADAS 8M | 3840x2160 | 8M | OX08B40 | MAX96717 | 8G+IRF | 30° | 16.8° | 23 | 23 | 43.75 |
| ADAS 5M | 2880x1860 | 5M | IMX490 | MAX9295A | 8G+IRF | 120° | 63.7° | 25 | 25 | 46.55 |
| ADAS 2M | 1920x1080 | 2M | OX03C10 | MAX96717F | 6G+IRF | 100° | 56° | 23 | 23 | 38.2 |
| SVC 5M | 2880×1860 | 5M | IMX490 | MAX96717 | 6G+IRF | 193° | 139° | 30 | 30 | 30.5 |
| SVC 3M | 1920x1536 | 3M | ISX031 | MAX96717F | 3G3P+IRF | 200° | 170° | 27 | 27 | 33.6 |
| SVC 2M | 1920x1080 | 2M | OX03C10 | MAX96717F | 2G4P+IRF | 196° | 112° | 23 | 23 | 33.1 |
| Side view 8M | 3840x2160 | 8M | OX08B40 | MAX96717 | 8G+IRF | 120° | 54° | 23 | 23 | 46 |
| Side view 5M | 2880x1860 | 5M | IMX490 | MAX96717 | 8G+IRF | 130° | 80° | 23 | 23 | 50.1 |
| Side view 2M | 1920x1080 | 2M | OX03C10 | MAX96717F | 6G+IRF | 99° | 54° | 23 | 23 | 36.2 |
| OMS 20M DOMS 5M | 2592x1944 (4 in 1) 2592x1944 | 20M 5M | OV20B40 OX05B1S | NA MAX96717 | 5P1G 2G4P+IRF | 85.6° 120° | 67.9° 80° | 12.3 - | 9.9 - | 7.82 - |
| OMS 2M | 1600x1300 | 2M | OV2312 | MAX9295A | 2G4P+IRF | 127° | 101° | 40 | 25 | 30.2 |
| DMS 1M | 1280×972 | 1M | AR0144 | MAX96705 | 4G+IRF | 65° | 34° | 48 | 25 | 26 |
| E-mirror 2M | 1920*384 | 2M | OX03C10 | MAX96701 | 6G+IRF | 69.8° | 13.8° | 25 | 25 | 32 |
| E-mirror 2M | 1920*1080 | 2M | ISX031 | MAX96717F | 6G+IRF | 69.8° | 39° | 30 | 25 | 34.5 |
| E-mirror 2M | 1920*384 | 2M | IMX623 | MAX96701 | 6G+IRF | 69.8° | 13.8° | 35 | 30 | 36.5 |
| CMS 2M | 1920x1080 | 2M | OX03C10 | MAX96717F | 6G+IRF | 99° | 54° | 23 | 23 | 36.2 |
